3RV-Af Froth Pump for Feeding Froth From 1+1 Flotation to Sump

Basic Info

Model NO.	3RV-AF
Position of Pump Shaft	Vertical Pump
Pump Casing Combined	Verticaljoint Surface Pump
Mounting Height	Suction Centrifugal
Impeller	Open
Usage	Pump, Pumps, Condensate Pump, Ash Pumps, Circulating Pump
Wear Resistance	Anti-Corrosion
Size	2 Inches, 3 Inches, 4 Inches, 6 Inches
Construction	Double Casings
Material of Wet End Parts	Ni-Hard, High Chrome Alloy, Rubber etc.
Drive Type	Bd/DC
Advantage	Easy Assembly & Disassembly, High etc.
Transport Package	Wooden Case
Specification	CE, ISO
Trademark	Naipu or OEM
Origin	China
HS Code	8413701090
Production Capacity	500sets/Month

Product Description

3RV-AF Froth pump for feeding froth from 1+1 flotation to sump
Naipu NP-AF froth pumps are of heavy duty construction, designed for continuous pumping of highly abrasive and corrosive frothy slurries. They have a vertical shaft configuration and comprise a hopper, with vertical bearing assembly, and type "NP-AH" pump wet end. They feature a wide choice of replaceable abrasion resistant metal or moulded elastomer casing liners and impellers.Typical Applications-Minerals Flotation Processing.Handle Froth slurriesProduct Overview:Construction Drawing:

Pump Performance Parameters

NAF Froth Pump Performance Parameters
Type	Allowable Mating Max. Power	Clear Water Performance				Impeller
		Capacity/Q m3/hr	Head/m	Speed/rpm	Max Effi.%	Impeller Dia./mm
2QV-NAF	15	7.2-33	5-30	800-1800	45%	229
3QV-NAF	20	10-104	10-28	700-1500	55%	268
4RV-NAF	40	15-130	6-28	500-1050	55%	397
6SV-NAF	75	55-330	6-25	350-680	55%	560

Except AF Froth Pump, we also produce other types slurry pumps.

Naipu Main Products

The Main pump model of AH HH M L SP AF G Series

AH series	L(R), M	HH	SP(R)	G	AF Series
1.5/1B-AH(R)	20A-L	1.5/1 C-HH	40PV-SP(R)	6/4D-G	2QV-AF
2/1.5B-AH(R)	50B-L(R)	3/2D-HH	65QV-SP(R)	8/6E-G	3QV-AF
3/2C-AH(R)	75C-L	4/3E-HH	100RV-SP(R)	10/8F-G	6SV-AF
4/3C-AH(R)	100 D-L	4/3X-HH	150SV-SP(R)	10/8S-G	8SV-AF
6/4D-AH(R)	150E-L	6/4F-HH	200SV-SP	12/10G-G
6/4E-AH(R)	300S-L	6/4X-HH	250TV-SP	14/12G-G
8/6E-AH(R)	10/8 R-M	6S-H		14/12T-G
8/6R-AH(R)	10/8 E-M	8/6S-H		16/14 G-G
10/8F-AH(R)		8/6X-H		16/14TU-GH
10/8X-AH(R)		6S-HP		16/14H-GH
12/10ST-AH(R)		8/6S-HP		18/16G-G
14/12ST-AH(R)		8/6X-HP		18/16 TU-GH
16/14TU-AH(R)
20/18G(TU)-AH(R)



Workshop Show:NAIPU PUMP is a whole processing company, Start from Modeling Workshop,Casting Workshop,Heat treatment Workshop,Machining Workshop ,Assembly Workshop and Pump Testing Workshop are all by us. So we are modernization and integrated company to satisfy the requirement of the changing needs of market.

Inspection Facilities



ApplicationsOur Froth Pumps are mainly used in COPPER TAILING TREATMENT.Such as follows,1.Froth pump for feeding froth from 1+1 flotation to sump2.Froth pump for feeding froth from flotation to flotation cell
3.Copper concentrate from flotation to thickener4.Froth pump for feeding froth from flotation to flotation cell.



Contact USSHIJIAZHUANG NAIPU PUMP CO.,LTDShijiazhuang Headquarters,Add: No.368 Xinshi North Road Shijiazhuang City, Hebei Province,China.Contact Person: Karen Tan
